| Model Name |
FUJIFILM GFX100 |
| Number of effective pixels |
102 million pixels |
| Image sensor |
43.8mm x 32.9mm Bayer array with primary color filter
- Sensor Cleaning system
- Ultra Sonic Vibration
|
| Storage media |
SD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-512GB) UHS-I / UHS-II / Video Speed Class V90*1 |
| File format |
- Still image
- JPEG (Exif Ver.2.3)*2, RAW : 14bit / 16bit RAW (RAF original format), RAW+JPEG, 8-bit /16-bit(10-bit output in 16bit file) TIFF (In-camera Raw Conversion Only)
|
| Number of recorded pixels |
L: (4:3) 11648×8736 / (3:2) 11648×7768 / (16:9) 11648×6552 / (1:1) 8736×8736 (65:24) 11648×4304 / (5:4) 10928×8736 / (7:6) 10192×8736
M: (4:3) 8256×6192 / (3:2) 8256×5504 / (16:9) 8256×4640 / (1:1) 6192×6192 (65:24) 8256×3048 / (5:4) 7744×6192 / (7:6) 7232×6192
S: (4:3) 4000×3000 / (3:2) 4000×2664 / (16:9) 4000×2248 / (1:1) 2992×2992 (65:24) 4000×1480 / (5:4) 3744×3000 / (7:6) 3504×3000
|
| Lens mount |
FUJIFILM G mount |
| Sensitivity |
- Standard Output Sensitivity
- AUTO1/AUTO2/AUTO3 (up to ISO12800) / ISO100-12800 (1/3 step)
(Movie: AUTO / ISO200-12800)
- Extended output sensitivity
- ISO50 / 25600 / 51200 / 102400
(Movie: ISO25600)
|
| Exposure control |
TTL 256-zone metering, Multi / Spot / Average / Center Weighted |
| Exposure mode |
P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure) |
| Exposure compensation |
-5.0EV - +5.0EV 1/3EV step
(Movie: -2.0EV - +2.0EV) |
| Image Stabilizer |
- Mechanism
- Image sensor shift mechanism with 5-axis compensation
- Compensation Effect
- 5.5 stops (based on CIPA standard). Pitch/yaw shake only. With GF63mmF2.8 R WR lens mounted.
|
| Shutter type |
Focal Plane Shutter |
| Shutter speed |
- Mechanical Shutter
- P mode: 4sec. to 1/4000sec. A mode: 30sec. to 1/4000sec.
S/M mode: 60min. to 1/4000sec. Bulb mode: up to 60min.
- Electronic Shutter*3
- P mode: 4sec. to 1/16000sec. A mode: 30sec. to 1/16000sec.
S/M mode: 60min. to 1/16000sec. Bulb mode: up to 60min.
- Electronic Front Curtain Shutter*4
- P mode: 4sec. to 1/4000sec. A mode: 30sec. to 1/4000sec.
S/M mode: 60min. to 1/4000sec. Bulb mode: up to 60min.
- Mechanical + Electronic Shutter*3
- P mode: 4sec. to 1/16000sec. A mode: 30sec. to 1/16000sec.
S/M mode: 60min. to 1/16000sec. Bulb mode: up to 60min.
- Electronic Front Curtain Shutter + Electronic Shutter*3*4
- P mode: 4sec. to 1/16000sec. A mode: 30sec. to 1/16000sec. S/M mode: 60min. to 1/16000sec. Bulb mode: up to 60min.
- Movie
- 1/4000sec.-1/4sec*.
- * Cannot choose slower shutter speed than framerate with LongGOP recording.
- Synchronized shutter speed for flash
- 1/125sec. or slower
|
| Continuous shooting |
CH Approx. 5.0fps
(JPEG: 41 Frames Lossless compression RAW: 14 Frames Uncompressed RAW: 13 Frames)
CL Approx. 2.0fps
(JPEG: Endless Lossless compression RAW: 20 Frames Uncompressed RAW: 15 Frames)
- *When Using the Electronic Shutter CH continuous shooting speed drops to approx. 2.9fps.
- *Electronic Front Curtain Shutter support CL only.
- *Recordable frame depends on recording media.
- *Speed of continuous shooting depends on shooting environment and shooting frames.
|
| Auto bracketing |
AE Bracketing (Frames: -2, -3, +3, +2, ±9, ±7, ±5, ±3 Step: 1/3EV, 2/3EV, 1EV, 4/3EV, 5/3EV, 2EV, 7/3EV, 8/3EV, 3EV)
Film Simulation bracketing (Any 3 types of film simulation selectable)
Dynamic Range Bracketing (100%, 200%, 400%)
ISO sensitivity Bracketing (±1/3EV, ±2/3EV, ±1EV)
White Balance Bracketing (±1, ±2, ±3)
Focus Bracketing (Frames: 1-999, Step: 1-10, Interval: 0-10s) |
| Focus |
- mode
- Single AF / Continuous AF / MF
- type
- Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
- AF frame selection
- Single point AF: EVF / LCD: 13×9 / 25×17 (Changeable size of AF frame)
Zone AF: 3×3 / 5×5 / 7×7 from 117 areas on 13×9 grid
Wide/Tracking AF: (up to 18 area) * AF-S: Wide / AF-C: Tracking
All
|
| White balance |
Automatic Scene recognition / Custom1-3 / Color temperature selection (2500K~10000K) / Preset: Fine, Shade, Fluorescent light (Daylight), Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light, Underwater |
| Self-timer |
10sec. / 2sec. |
| Interval timer shooting |
Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing) |
Flash modes
*When EF-X500 is set |
- SYNC. MODE
- 1ST CURTAIN / 2ND CURTAIN / AUTO FP(HSS)
- FLASH MODE
- TTL (TTL AUTO (P mode) / STANDARD / SLOW SYNC. ) / MANUAL / MULTI / OFF
|
| Hot shoe |
Yes (Dedicated TTL Flash compatible) |
| Viewfinder |
0.5 inch Approx. 5.76 million dots OLED Color Viewfinder
Coverage of Viewing Area vs. Capturing Area: Approx. 100%
Eyepoint: Approx. 23mm (from the Rear End of the Camera's Eyepiece)
Diopter Adjustment: -4 - +2m-1
Magnification: 0.86× with 50mm Lens (35mm Equivalent) at infinity
and Diopter set to -1.0m-1
Diagonal Angle of View: Approx. 41° (Horizontal Angle of View: Approx. 33°)
Built-In Eye Sensor |
| LCD monitor |
3.2 inch, Aspect Ratio 4:3, Approx. 2.36 million dots Tilt-Type(Three Direction), Touch Screen Color LCD Monitor (Approx. 100% Coverage) |
| Touch Screen Mode |
- Shooting Mode
- Touch AF, Focus Area, OFF
Double Tap ON/OFF Setting, Touch Function ON/OFF Setting
- Playback Mode
- Swipe, Zoom, Pinch-in / Pinch-out, Double-tap, Drag (ON/OFF Selectable)
|
| Sub LCD monitor |
1.80 inch, Aspect Ratio 4:3, 303×230-dot Monochrome LCD Monitor |
| Rear sub monitor |
2.05 inch, Aspect Ratio 4:1, 256×64-dot Monochrome OLED Monitor |
| Movie recording |
- File format
- MOV (MPEG-4 AVC / H.264, HEVC / H.265, Audio : Linear PCM / Stereo sound 24bit / 48KHz sampling)
- Movie compression
- All Intra/Long-GOP
- * All Intra can be used with following settings.
DCI4K/4K 29.97p/25p/24p/23.98p 400Mbps
Full HD(2048×1080)/Full HD(1920×1080) 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps
- File size / Frame rate / Recording time
- [DCI4K (4096×2160)]
29.97p / 25p / 24p / 23.98p 400Mbps/200Mbps/100Mbps up to Approx. 60min.
[4K (3840×2160)]
29.97p / 25p / 24p / 23.98p 400Mbps/200Mbps/100Mbps up to Approx. 60min.
[Full HD (2048×1080)]
29.97p / 25p / 24p / 23.98p 200Mbps/100Mbps/50Mbps up to Approx. 80min.
[Full HD (1920×1080)]
29.97p / 25p / 24p / 23.98p 200Mbps/100Mbps/50Mbps up to Approx. 80min.
- * For recording movies, use a SD memory card with UHS Speed Class 3 or higher.
- * For recording movies in 400Mbps, use a SD memory card with Video Speed Class 60 or higher.
- * Recording movies in 400Mbps can be done with DCI4K/4K 29.97p/25p/24p/23.98p.
|
| Film Simulation mode |
16 modes ( PROVIA / Standard, Velvia / Vivid, ASTIA / Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, ETERNA / CINEMA, Black&White, Black&White+Ye Filter, Black&White+R Filter, Black&White+Gfilter, Sepia, ACROS, ACROS+Ye Filter, ACROS+R Filter, ACROS+G Filter ) |
| B & W ADJ. (Warm/Cool) |
-9 - +9
- *When ACROS or Black&White is selected.
|
| Grain Effect |
STRONG, WEAK, OFF |
| Color Chrome Effect |
STRONG, WEAK, OFF |
| Smooth Skin Effect |
STRONG, WEAK, OFF |
| Dynamic range setting |
AUTO, 100%, 200%, 400% |
| Photography functions |
D range priority, Highlight tone, Shadow tone, Color, Sharpness, Noise reduction, Long exposure NR, Lens Modulation Optimizer, Color space, Pixel mapping, Select custom setting, Edit/Save custom setting, AF-C custom setting, Store AF mode by orientation, AF point display, Pre-AF, AF Illuminator, Face/Eye detection AF, AF+MF, MF assist(Digital Split Image, Digital Microprism, Focus peak highlight), Focus check, Interlock spot AE & focus area, Instant AF setting (AF-S/AF-C), Depth-of-field scale, Release/Focus priority, Touch screen mode, Flicker reduction, Mount adapter setting, 35mm Format Mode, Red eye removal, RGB Histogram, Highlight alert, Electronic level, Preview depth of field, AE lock, AF lock, AF-ON, AWB lock, Multiple exposure |
| Movie functions |
Interframe NR, F-Log/HLG recording, Peripheral light correction, Movie AF mode, 4K movie output, Full HD movie output, HDMI output info display, 4K HDMI standby quality, HDMI rec control, Zebra setting, Zebra level, Audio setting, Time code setting, Tally light, Movie silent control |
| Playback functions |
Switch slot, RAW conversion, Erase, Erase selected frames, Simultaneous delete(Raw Slot1/JPG Slot2), Crop, Resize, Protect, Image rotate, Red eye removal, Voice memo setting, Copy, Photobook assist, Multi-frame playback (with micro thumbnail), Favorites, RGB histogram, Highlight alert |
| Wireless transmitter |
- Standard
- IEEE802.11a/b/g/n/ac (standard wireless protocol)
- Encryption
- WEP/WPA/WPA2 mixed mode
- Access mode
- Infrastructure
|
| Bluetooth® |
- Standartds
- Bluetooth Ver. 4.2(Bluetooth low energy)
- Operating frequency
- 2402 - 2480MHz(Center frequency)
|
| Wireless function |
Geotagging, Image transfer (Individual image/Selected multiple images), View & Obtain Images, instax Printer Print, Pairing registration, Delete pairing registration, Bluetooth ON/OFF setting, Auto image transfer, Smartphone Sync. Setting, Wireless com. frequency setting |
| Other functions |
Exif Print, Date/Time, Time difference, 35 Languages, My menu setting, Sensor cleaning, Battery age, Regulatory, Sound set-up, EVF brightness, EVF color, EVF color adjustment, LCD brightness, LCD color, LCD color adjustment, Image disp, Auto rotate displays, Preview exp./WB in manual mode, Natural live view, Framing guideline, Auto rotate PB, Focus scale units, Dual display setting, Disp. custom setting, Large indicators mode(EVF/LCD), Large indicators disp. setting, Information contrast adj. Sub monitor setting, Rear sub monitor setting, Sub monitor background color, Rear sub monitor brightness, Focus lever setting, Edit/Save Quick menu, Function(Fn) setting, Command dial setting, Shutter AF, Shutter AE, Shoot without lens, Shoot without card, Focus ring, Focus ring operation, AE/AF-Lock mode, AWB-Lock mode, Expo. Comp. button setting, Touch screen setting, Lock, Auto power off, Performance, Shooting stand by mode, Auto power save, Frame No., Save org image, Edit file name, Card slot setting, Select slot, Select Folder and Create Folder, Copyright Info |
| Terminal |
- Digital interface
- USB Type-C(USB3.2 Gen1x1)
- HDMI output
- HDMI Micro connector (Type D)
- Other
- ø3.5mm, stereo mini connector (Microphone)
ø3.5mm, stereo mini connector (Headphone)
ø2.5mm, Remote Release Connector
DC IN 15V Connecter *Compatible with AC-15V (Optional) Only
Hot shoe
Synchronized terninal
|
| Power supply |
NP-T125 (x2) Li-ion battery (included)
- Battery life for still images*6
- Approx. 800 frames When GF63mmF2.8 R WR is set. (2 batterys installed, Auto power save ON)
- Actual battery life of movie capture*6
- *Face detection is set to OFF
- [4K] Approx. 100min. [Full HD] Approx. 150min.
- Continuance battery life of movie capture*6
- *Face detection is set to OFF
- [4K] Approx. 170min. [Full HD] Approx. 240min.
|
| USB power supply |
Support USB PD(Power Delivery) power source to supply or rapidly recharge battery (USB PD Rev2.0 ver1.3) |
| Dimensions |
Including EVF
156.2mm (W) × 163.6mm (H) × 102.9mm (D) / 6.15in. (W) × 6.44in. (H) × 4.05in. (D)
(Minimum Depth : 48.9mm / 1.93in.)
Excluding EVF
156.2mm (W) × 144.0mm (H) × 75.1mm (D) / 6.15in. (W) × 5.67in. (H) × 2.96in. (D)
(Minimum Depth : 48.9mm / 1.93in.) |
| Weight |
Approx. 1,400g / 49.4oz. (including EVF, battery x2 and memory card)
Approx. 1,320g / 46.6oz. (including battery x2 and memory card)
Approx. 1,155g / 40.7oz. (excluding accessories, battery and memory card) |
| Operating Temperature |
-10°C - +40°C (+14°F - +104°F) |
| Operating Humidity |
10 - 80% (no condensation) |
| Starting up period |
Approx 0.4sec.
|
| Accessories included |
Li-ion batteries NP-T125 (x2)
Battery charger BC-T125
Plug adapter
Interchangeable electronic viewfinder EVF-GFX2
Body cap, Metal strap clips (x2)
Clip attaching tool
Protective covers (x2)
Shoulder strap
Cable protector
Hot shoe cover (Body/EVF)
Connector cover (EVF)
Sync terminal cover
Owner's manual |
